Mech-Q
Mech-Q: High-Efficiency CAD Utilities for Advanced Engineering Design
Streamline your detailing workflows, ensure industry compliance, and eliminate repetitive drafting tasks. Mech-Q delivers a robust suite of precision CAD utilities engineered specifically for professionals who demand technical accuracy and accelerated project delivery.
Our specialized software integrates seamlessly into your existing CAD environment, providing enterprise-grade tools across a diverse range of high-demand sectors:
- Energy & Infrastructure: Power Generation, Petrochemical, Mining, and Heavy Industry.
- Process & Manufacturing: Food & Beverage, Pharmaceutical, Pulp & Paper, and Biotechnology.
- Defense & Specialized Layouts: Military, Marine, and Commercial Structural Design.
A Comprehensive, Discipline-Specific Toolkit
Whether you need to deploy targeted tools for a specific project or equip an entire department, Mech-Q offers scalable solutions across four core engineering disciplines:
 |
Mech-Q Piping Pro software module: 2d/3d Othogonal, Isometric & P&ID - Includes a huge range of pipe, fittings, flanges and valves. Welded, flanged, threaded, screwed, ductile iron & cast iron, "Victaulic", PVC... and several other piping systems. The module is equipped with features like: Auto-BOM. |
 |
Mech-Q Mechanical software module includes a comprehensive range of mechanical symbols, fasteners, gears, material handling items (conveyor rolls, sprockets, trajectory..), springs, shafts & more. More details |
 |
Mech-Q HVAC Ducting software module - 2D & 3D Ducting made easy. Rectangular, round and flat oval. Several Duct and Duct fittings included: Duct bends, transitions, tees & wyes, offsets, branches, dampers, diffusers, flexible duct. With Auto-BOM and Auto-Labelling. More details |
 |
Mech-Q Structural Pro software module is utilised for the drawing of structural steel drawings. It includes steel shapes from around the world, Draw beams & columns with ease, beam-connections, stairs, ladders, bracing, hand railing, frames, welding symbols, beam loading designer. More details |
Deployment Flexibility: Every module is available as a standalone application to target specific project needs, or bundled together in the complete Mech-Q Engineering Suite to maximize your software ROI and enable cross-discipline integration.
Mech-Q CAD compatibility
Our engineering suite will run inside a wide range of CAD software including AutoCAD, ALL AutoCAD Verticals, AutoCAD LT, Bricscad, CADian, GstarCAD, progeCAD, CADMATE and several other IntelliCAD versions.
We now support AutoCAD LT2024 to LT2027 (2D only)
Do not have a CAD program? Our 2D/3D AviCAD Professional CAD also includes our Mech-Q software with a powerful 2d/3d CAD software (Click here for details)
Like to have Mech-Q, but not have CAD?
We can include 2D/3D CAD For FREE
Complete your engineering drawing like a champion
If you are like most draftspersons you know how hard it is to meet deadlines. Automating your workflow is essential in order to keep up with hectic schedules. Our engineering tools makes it really easy to get going. Even non-technical users will be able to easily use our menus and dialogs without having to draw a single line.
Technical Advantages: Why Engineering Designers Deploy Mech-Q
1. Native CAD Integration & Zero Workflow Disruption
Mech-Q embeds directly into your existing CAD host environment, preserving your established drafting interface and keyboard shortcuts. This eliminates the steep learning curves, exorbitant licensing overhead, and file-conversion friction typical of bulky, standalone BIM platforms. Designers gain advanced automation capabilities immediately, without disrupting proven project delivery pipelines.
2. Parametric Precision & Mitigated Design Risk
Eradicate manual geometry calculations, manual scaling, and drafting human error. By utilizing intelligent, fully parametric algorithms, Mech-Q ensures that all components, profiles, and configurations automatically conform to rigorous global standards (including ANSI, ISO, and DIN). This safeguards design integrity from the initial layout phase and prevents costly field changes or fabrication reworks.
3. Scalable Architecture & Optimized Software ROI
Align your software expenditure directly with your project pipeline. Mech-Q’s modular deployment model allows engineering leads to license only the discipline-specific toolsets required for immediate contract scopes—such as Piping or Piping + HVAC. Alternatively, teams can scale up to the complete Engineering Suite to effortlessly manage complex, multi-disciplinary project deliveries under a single, cost-effective framework.
Licenses options:
| Perpetual License One time pay From $499 |
Monthly Subscription Fr. $29/month |
Yearly Subscription Fr. $199 |
- 12 months Service & Maintenance included free when you purchase a new Mech-Q license
- Network (floating) One to Unlimited seats option available
Piping Software CAD Piping Software Piping Software for AutoCAD Ducting Software HVAC Ducting Software CAD Duct Software Ducting Software for AutoCAD Structural Software Structural CAD Software Structural detailing software Structural Software for AutoCAD Mechanical Software Mechanical CAD Software Mechanical Software for AutoCAD BOM Software AutoCAD Applications AutoCAD add-on Software CAD Blocks Free CAD Free Software Free Download
Reviews
(Based on 1 review)
| Posted by: PP |
Mech-QMECH-Q for progeCAD 2 of 3 people found this useful |
Was this review useful? |
Mech-Q Mechanical CAD Software
Mech-Q Mechanical CAD is one of the most useful software packages for a mechanical design engineer using AutoCAD® or similar CAD Software.
This add-on application is a must for most mechanical engineering CAD professionals involved in all aspects of mechanical design or mechanical 2d and 3d drafting. This mechanical cad software module is also very useful for engineering and drafting professional involved in material handling.
Included with the Mech-Q Mechanical Software module:
- Fasteners: Huge range of bolts, screws, nuts, pins & clips
- Bearings & Bearing housings
- Shafts, gears, spigots, keys & keyways
- Springs: Extension Springs & Compression Springs design
- Material Handling: Conveyor equipment, Sprockets, Trajectory calculations
The Mech-Q CAD mechanical software module also includes several very useful functions, including:
- Auto Dimensioning
- Table generation
- Auto Detailings
- Text, layers, and dimensioning tools
- Multitude of mechanical symbols, mechanical drafting tools and mechanical functions. More details...
Mech-Q CAD Piping Software
With Mech-Q Piping CAD Software, you can create, modify, and manage piping and instrumentation diagrams in AutoCAD® or similar CAD design software. This add-on to CAD, it is familiar to many designers and engineers. With simple design, reporting & editing tools for drawing piping layouts for all kinds of piping projects.
The Mech-Q Piping CAD module is used piping professionals involved in process piping, pharmacutical plants, petrochemical plant design, nuclear piping, building services design.
The Mech-Q Piping CAD Software module includes:
- Othogonal 2d/3d CAD Piping Software
- Isometrical Piping Software
- P&ID Software
- Plumbing symbols
- Fabricated (lobster-back) piping
- Pipe hangers, clamps, pumps, cylinders, tanks and several other piping software modules.
Features include: Auto-BOM, auto-labeling and easy editing. Full control and customization of layers.
Part of this piping software module is the database editor that allows you to change, add or delete pipe and pipe fittings to the existing comprehensive range.
Several types of pipe & pipe fittings included: Butt welded, socket welded, threaded, grooved, tubing, mechanical joint, sanitary, soil piping, electrofusion, PVC, Ductile iron and cast iron piping More details...
Mech-Q HVAC Ducting CAD Software
The Mech-Q HVAC Ducting Software module is a great tool for Ducting profesionals involved in Air Conditioning, heating and vetilation projects.
The Ducting Software draws in 2D & 3D rectangular, round and flat oval duct and duct fittings - the CAD ducting software module makes Duct drawing and duct design easy. The module includes:
- Straight duct.
- Several Duct fittings included: Duct bends, transitions, tees & wyes, offsets, branches, dampers, diffusers, flexible duct.
- With features including Auto-BOM and Auto-Labelling. More Details...
Mech-Q Structural CAD Software
The Mech-Q Structural CAD Detailing SOftwrae module is used for the drawing of structural steel drawings. This structural software package includes powerful structural module for the drawing of:
- Steel shapes from around the world (AISC, BHP, CISC, DIN, RSA, JIS, IS, Chinese)
- Beams & columns are drawn with ease
- Beam-connections
- Stairs, ladders, bracing, hand railing, frames, welding symbols
- Beam loading designer.
- Features include: Auto-BOM, Easy customization, layers control and a database editor that allows you to change, add or delete steel shapes to the existing already comprehensive range. More details...
The Mech-Q CAD software supports both Metric & English (Imperial) Units.
Mech-Q
Monthly / Yearly Subscriptions Available
Please choose your product to see optionsFind out more
For Quantities of 3 or more please contact us
$899.00
On Sale:
Order / Buy
Subscription option not available for this CAD version
Your purchase will include 12 months Service & Maintenance
FREE updates & upgrades for 12 months
